Model:FIM-600K

Subject		Unit	Technical parameter
Power supply		Voltage/Phase/Frequency	380V/3P/50Hz
Refrigerant			R22 or R404A
Capacity		Kg/day	60000
Cooling way			Water cooling
Temperature	Ambient temperature	℃	35
Temperature	Waterinlet temperature	℃	20
Compressor	Manufacturer		GRASSO
	Refrigeration capacity	Kw	350
	Total running power	Kw	195
	Compressor COP/EER	Kw/kw	1.8
	Horse power	Hp	350×1set
Operating power	Total running power	Kw	214.9
	Installment power	Kw	280
	Operating power of reducer	Kw	3.7
	Operating power of cold water pump	Kw	1.5
	Cooling water pump	Kw	11
	Fan of cooling tower	Kw	3.7
Diemnsion	Size of ice maker	(L×W×H)(mm)	Unit:3400×2200×2200
	Size of ice maker	(L×W×H)(mm)	Evaporator:3000×2500×4500
	Size of cooling tower	(O.D.×H)(mm)	Φ3770×3490
	Size of water feeding pipes of cooling tower		1"
	Size of cooling water pipes		6"
	Size of water feeding pipe		1"
	Size of ice outlet	mm	Φ2160
Weight of unit	Operating weight of flake ice maker	Kg	Unit:4500
	Operating weight of flake ice maker	Kg	Evaporator:6500
	Operating weight of cooling tower	Kg	3640
Water supply pressure requirement		Bar	1.5
