- | Simple structure, light weight, convenient transport. |
- | All interface is covered by stainless steel 304, completely conform to food hygiene standard. |
- | Customized feed inlet, suitable for 3 tons -20 tons of different output ice maker; |
- | Foot and program automatic combination control technology, weighing arbitrary; |
- | Equipped with automatic overload equipment, so that the machine automatically stop in case of excessive power; |
- | Equipped with SIEMENS high quality motor, packaging 150 thousand times, no trouble; |
- | The equipment parts are made by the world famous brand: power control: Schneider (France); sensors: OMRON (Japan); switch: Schneider (France). |
Mode | Packing capacity | Outline size (length*width*height mm) |
Packing range | Average packing speed | diameter |
---|---|---|---|---|---|
FIP-01D-I | 500Kg/hr | 1980*600*1775 | 5Kg~10Kg | 4bags/min | 150mm |
FIP-01D-II | 800Kg/hr | 1600*600*1775 | 11Kg~18Kg | 2bags/min | 180mm |
Remark: The user shall choose according to the weight of the ice in the bag. The packaging capacity of ice packs will affect the packaging speed and the daily ice content of the packaging machines.
Voltage: 380V 50/60HZ 1KW
Loading capacity: 10L
Length of screw: customized according to different demands
