ITEM |
UNIT |
TECHNICAL PARAMETER |
|
|---|---|---|---|
Input power |
voltage/phase/HZ |
380V/3P/50Hz |
|
Refrigerant |
|
R22 or R404A |
|
Ice field |
Kg/day |
5000 |
|
Cooling way |
|
Water cooling |
|
Temperature |
Ambient temperature |
℃ |
35 |
Water Inlet temperature |
℃ |
20 |
|
Running power |
Total running power |
kw |
20.9 |
Installed power |
kw |
25 |
|
Cooling tower fan |
kw |
0.55 |
|
Water cooling pump |
kw |
1.5 |
|
Water cooling pump power |
kw |
0.55 |
|
Compressor |
Manufacture |
|
Bitzer |
Refrigerating capacity |
kw |
43.3 |
|
Running power |
kw |
17.99 |
|
Compressor COP/EER |
Kw/kw |
2.41 |
|
Horsepower |
Hp |
25 |
|
Working time |
Ice making time |
hour（h） |
7.5 |
Ice doffing time |
hour（h） |
0.5 |
|
Outline size |
Block ice specifications |
Kg/block |
50 |
Block ice machine outline size |
(length×width×height)(mm) |
480×160×700 |
|
Machine modular outline size |
(length×width×height)(mm) |
1400×1000×1250 |
|
Evaporator module quantity |
|
1 piece |
|
Evaporator module outline size |
(length×width×height)(mm) |
4800×1000×2200 |
|
Cooling tower outline size |
（external diameter×height）（mm） |
Ф1380×2170 |
|
Dimensions of water supply pipe cooling tower |
|
4parts（1/2"） |
|
Cooling water pipe size |
|
2inches（2"） |
|
Inlet pipe size of ice machine |
|
1-1/4inch（1-1/4"） |
|
Running weight |
Machine unit |
kg |
960 |
Evaporator |
kg |
2860 |
|
Cooling tower |
kg |
460 |
|
Water pressure requirements |
Bar |
1 |
|
