ITEM |
UNIT |
TECHNICAL PARAMETER |
|
|---|---|---|---|
Input power |
Voltage/phase/HZ |
380V/3P/50Hz |
|
Refrigerant |
|
R22 or R404A |
|
Ice yield |
Kg/day |
1000 |
|
Cooling way |
|
Air cooling |
|
Temperature |
Ambient temperature |
℃ |
35 |
Water Inlet temperature |
℃ |
20 |
|
Running power |
Total running power |
kw |
5.7 |
Installed power |
kw |
10 |
|
Compressor |
Manufacture |
|
Bitzer |
Refrigerating capacity |
kw |
5 |
|
Running power |
kw |
4.59 |
|
Compressor COP/EER |
Kw/kw |
2.0 |
|
Horsepower |
Hp |
5×1 sets |
|
Working time |
Ice making time |
hour（h） |
5.5 |
Ice doffing time |
hour（h） |
0.5 |
|
Outline size |
Block ice specifications |
Kg/block |
5, 10 |
Block ice machine outline size |
(length×width×height)(mm) |
4000×1000×1200 |
|
Machine modular outline size |
(length×width×height)(mm) |
1700×1000×1200 |
|
Evaporator module quantity |
|
1 piece |
|
Evaporator module outline size |
(length×width×height)(mm) |
1700×1000×1150 |
|
Inlet pipe size of ice machine |
|
DN40 |
|
Running weight |
Machine unit |
kg |
350 |
Evaporator |
kg |
300 |
|
Water pressure requirements |
Bar |
1 |
|
