ITEM |
UNIT |
TECHNICAL PARAMETER |
|
|---|---|---|---|
Input power |
Voltage/phase/HZ |
380V/3P/50Hz |
|
Refrigerant |
|
R22 or R404A |
|
Ice yield |
Kg/day |
8000 |
|
Temperature |
Ambient temperature |
℃ |
35 |
Water Inlet temperature |
℃ |
20 |
|
Running power |
Running power |
kw |
30.79 |
Installed power |
kw |
37.5 |
|
Cooling water pump running power |
kw |
2.2 |
|
Compressor |
Manufacture |
|
Bitzer |
Refrigerating capacity |
kw |
86.6 |
|
Running power |
kw |
35.98 |
|
Compressor COP/EER |
Kw/kw |
2.41 |
|
Horsepower |
Hp |
25×2 |
|
Condenser |
Running power |
kw |
3.3 |
Cooling way |
|
Water cooling |
|
Working time |
Ice making time |
hour（h） |
7.5 |
Ice doffing time |
hour（h） |
0.5 |
|
Outline size |
Block ice specifications |
Kg/block |
50 |
Block ice specifications |
(length×width×height)(mm) |
480×160×700 |
|
Cooling tower outline size |
(length×width×height)(mm) |
Ф2000×2410mm |
|
Dimensions of water supply pipe cooling tower |
|
1-1/4inch |
|
Cooling tower total running weight |
kg |
670 |
|
Water pressure requirements |
Bar |
1 |
|
