ITEM |
UNIT |
TECHNICAL PARAMETER |
|
---|---|---|---|
Input power |
Voltage/phase/HZ |
380V/3P/50Hz |
|
Refrigerant |
|
R22 or R404A |
|
Ice yield |
Kg/day |
12500 |
|
Cooling way |
|
Water cooling |
|
Temperature |
Ambient temperature |
℃ |
35 |
Water Inlet temperature |
℃ |
20 |
|
Running power |
Total running power |
kw |
54.35 |
Installed power |
kw |
70 |
|
Cooling tower fan |
kw |
1.1 |
|
Cooling water pump |
kw |
2.2 |
|
Cooling water pump running power |
kw |
0.55 |
|
Compressor |
Manufacture |
|
Bitzer |
Refrigerating capacity |
kw |
97.8 |
|
Running power |
kw |
45.34 |
|
Compressor COP/EER |
Kw/kw |
3.93 |
|
Horsepower |
Hp |
25×2 sets |
|
Working time |
Ice making time |
hour(h) |
7.5 |
Ice doffing time |
hour(h) |
0.5 |
|
Outline size |
Block ice specifications |
Kg/block |
50 |
Block ice machine outline size |
(length×width×height)(mm) |
480×160×700 |
|
Machine modular outline size |
(length×width×height)(mm) |
1800×1000×1450 |
|
Evaporator module quantity |
|
2 pieces |
|
Evaporator module outline size |
(length×width×height)(mm) |
4800×1000×2200 |
|
Cooling tower outline size |
(external diameter×height)(mm) |
Ф2000×2410 |
|
Dimensions of water supply pipe cooling tower |
|
3/4part(3/4") |
|
Cooling water pipe size |
|
2-1/2inch(2-1/2") |
|
Inlet pipe size of ice machine |
|
1-1/4inch(1-1/4") |
|
Running weight |
Machine unit |
kg |
1680 |
Evaporator |
kg |
2860 |
|
Cooling tower |
kg |
670 |
|
Water pressure requirements |
Bar |
1 |
